Ricoh SP 330DN Service Manual

Smart Organizing Monitor (SOM)
SM 5-49 M0C3/M0C4/M0C5/M0C6/M0C7
System
Maintenance
Group Item Remarks
Registration Roller: Tray 2 Paper
Vertical: Thick
Paper
[-8 to 8 / 0* / 1 mm/step]
Vertical: Thin
Paper
[-8 to 8 / -2* / 1 mm/step]
Amount of Paper Buckle at the
Registration Roller: Bypass Tray
Vertical: Plain
Paper
[-8 to 8 / -2* / 1 mm/step]
Vertical: Thick
Paper
[-8 to 8 / 0* / 1 mm/step]
Vertical: Thin
Paper
[-8 to 8 / -2* / 1 mm/step]
Amount of Paper Buckle at the
Registration Roller: Duplex Tray
Vertical: Plain
Paper
[-8 to 8 / 0* / 1 mm/step]
Vertical: Thick
Paper
[-8 to 8 / 0* / 1 mm/step]
Vertical: Thin
Paper
[-8 to 8 / 0* / 1 mm/step]
Fusing Temperature Plain Paper
Adjusts the fusing temperature for each
paper type.
[150 to 200 / 175* / 1°C/step]
Thick Paper 1 [170 to 200 / 185* / 1°C/step]
Thin Paper [155 to 180 / 170* / 1°C/step]
Envelope [170 to 200 / 185* / 1°C/step]
Thick Paper 2 [175 to 200 / 185* / 1°C/step]
Recycled [160 to 180 / 170* / 1°C/step]
Standby
Mode
[120 to 175 / 155* / 1°C/step]
Low Power
Mode
[80 to 135 / 120* / 1°C/step]
SC559 Detection [On or Off *]
Print Test Pattern Prints the test pattern.
Refill Mode Setting
[Auto refill mode */ Pure refill mode]
DFU
Handling Mode on "Waste Toner full" of the refilled
AIO
Sets the machine operation at "waste toner
full" of the refilled AIO.
[On or Off *]

Ricoh SP 330DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	32 ppm
Printing colors	Black, White
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Multi-Purpose tray	Yes
Total input capacity	550 sheets
Total output capacity	125 sheets
Paper tray media types	-
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
USB connector	USB Type-B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Sound pressure level (printing)	- dB
Market positioning	Home & office
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.72 W
Energy Star Typical Electricity Consumption (TEC)	0.41 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur
Server operating systems supported	Windows Server 2008, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	262 mm
