5.System Maintenance
109
Menu
Description
to stop printing after the print total exceeds a certain set value. If the
print count exceeds this value, then "Replace Print Cartridge"
remains in the display. Then a new AIO cartridge must be installed.
This feature is a safety measure to prevent the used toner tank from
becoming full (there is no toner overflow detection mechanism).
1200DPI Power
Adjusts print density (density levels by increasing the number)
[42 to 106 / 74 (Default) / 1 /step]
Refill Mode
DFU
[Auto refill mode/ Pure refill mode]
Page Dot
Coverage
0%-2%
Displays the number of pages printed with coverage 0 to 2%.
3%-4%
Displays the number of pages printed with coverage 3 to 4%.
5%-7%
Displays the number of pages printed with coverage 5 to 7%.
8%-9%
Displays the number of pages printed with coverage 8 to 9%.
10%-19%
Displays the number of pages printed with coverage 10 to 19%.
20%-29%
Displays the number of pages printed with coverage 20 to 29%.
Above 30%
Displays the number of pages printed with coverage above 30%.
Power On Count
Displays the power on counter.
Sleep Recover Count
Displays the sleep recover counter.
Machine Series Number
DFU
Displays the machine series number.
Serial No
DFU
Displays the machine serial No.
Inrush Control
Sets the Inrush Control mode. When using with an external power
supply instead of a commercial power supply, set to "On".
[Off (Default)/ On]
Flicker Control
Sets the Flicker Control mode.
[Off (Default)/ On]
Scan Maintenance (Only for MF Models)
Menu
Description
Mono Compression
Sets the monochrome compression type for scanning.
MH (Default)/ MR/ MMR
Registration Adjust
ADF Main Reg.
Adjusts the ADF Scan main-scan registration.
[-2.0 to 2.0 / 0 (Default)/ 0.1 mm/step]
ADF Sub Reg.
Adjusts the ADF Scan sub-scan registration.
[-2.0 to 2.0 / 0 (Default)/ 0.1mm/step]
Flatbed Main Reg.
Adjusts the Flatbed Scan main-scan registration.
