Ricoh SP 3710DN Field Service Manual

2.Installation
17
Center GUI.
Four-line LCD panel: SP menu > [@Remote] > [Remote Service] > [Instl:Ref Section]
Touch panel: SP menu > [@Remote] > [Remote Service] > [Confirm Place]
8. Execute the registration.
Four-line LCD panel: SP menu > [@Remote] > [Remote Service] > [Instl:Rgstltn]
Touch panel: SP menu > [@Remote] > [Remote Service] > [Register Execute]
9. Check the registration result.
Four-line LCD panel: SP menu > [@Remote] > [Remote Service] > [Instl:Rgstltn Rst]
Touch panel: SP menu > [@Remote] > [Remote Service] > [Register Result]
Value
Meaning
Solution/ Workaround
0
Succeeded
-
2
Already registered
Check the registration status.
3
Communication error (proxy enabled)
Check the network condition.
4
Communication error (proxy disabled)
Check the network condition.
5
Proxy error (Authentication error)
Check the proxy user name and password.
8
Other error
See "Error Codes" below this.
9
Request number registration executing
Processing… Please wait.
After Settings
The first manual call after setting is considered as a test call. Be sure to execute the test call, or the first
manual call from the customer will be considered as the test call.
.
1. Enter the "Maintenance Mode (SP mode)".
2. Execute the "Manual Call".
Four-line LCD panel: SP menu > [@Remote] > [Remote Service] > [Remote Diagnostics]
Touch panel: SP menu > [@Remote] > [Remote Service] > [Remote Diagnostics]
3. "Running…" is displayed for about 3 seconds. This message disappears automatically after 3
seconds, and then returns to [Remote Service] menu.
Error Codes
When other errors occur, check the following error code list.
Four-line LCD panel: SP menu > [@Remote] > [Remote Service] > [Instl: ErrorCode]
Touch panel: SP menu > [@Remote] > [Remote Service] > [Error Code]
Caused by Operation Error, Incorrect Setting
Code
Meaning
Solution/ Workaround
-12003
Attempted registration without execution of a
confirmation and no previous registration.
Perform Confirmation before attempting
the Registration.
-12004
Attempted setting with illegal entries for
Check the ID2 of the machine.

Ricoh SP 3710DN Specifications

General

Color	No
Duplex printing	-
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	32 ppm
Printer fonts	PCL, PostScript
Printing colors	Black
Maximum duty cycle	- pages per month
Page description languages	PCL 5e, PCL 6, PostScript 3
Total input capacity	300 sheets
Total output capacity	125 sheets
Maximum input capacity	550 sheets
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.72 W
Power consumption (printing)	- W
Sustainability compliance	Yes
Sustainability certificates	ENERGY STAR
Sound pressure level (printing)	- dB
Product color	Black, White
Market positioning	Home & office
USB connector	USB Type-B
USB 2.0 ports quantity	1
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Server operating systems supported	Windows Server 2008, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1
Included cartridge capacity (black)	7000 pages

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	262 mm
