Chapter 2 Command System RIGOL
DL3000 Programming Guide 2-21
activated list command. WAVe: indicates that the input regulation mode is
determined by the waveform display command. BATTery: indicates that the input
regulation mode is determined by the battery discharge command. OCP: indicates
that the input regulation mode is determined by the OCP command. OPP: indicates
that the input regulation mode is determined by the OPP command.
 The query returns LIST in List mode; returns WAV in waveform display interface;
returns BATT in battery discharge mode; returns OCP in OCP mode; returns OPP in
OPP mode; returns FIX in other modes.
Return
Format
The query returns FIX, LIST, WAV, BATT, OCP, or OPP.
Example :SOUR:FUNC:MODE FIX /*Sets the input regulation mode to be controlled by the
FUNCtion command.*/
:SOUR:FUNC:MODE? /*Queries what controls the input regulation mode.*/
Related
Command
[:SOURce]:FUNCtion
[:SOURce]:TRANsient
Syntax [:SOURce]:TRANsient[:STATe] {0|1|ON|OFF}
[:SOURce]:TRANsient[:STATe]?
Description Sets the trigger function to be on or off.
Queries the state of the transient generator.
Remarks
 Running this command produces the same effect as pressing the TRAN key.
 In the local operation mode, press the TRAN key on the front panel, and then one
trigger operation is executed.
Return
Format
The query returns 0 or 1. 0 indicates that the trigger function is off, and 1 indicates that
the trigger function is on.
Example :SOUR:TRAN:STAT 1 /*Sets the trigger function to be on.*/
:SOUR:TRAN:STAT? /*Queries the state of the trigger function.*/
[:SOURce]:CURRent[:LEVel][:IMMediate]
Syntax [:SOURce]:CURRent[:LEVel][:IMMediate] {<value>|MINimum|MAXimum|DEFault}
[:SOURce]:CURRent[:LEVel][:IMMediate]? [MINimum|MAXimum|DEFault]
Description Sets the load's regulated current in CC mode.
Queries the load's regulated current set in CC mode.
Remarks  The load's regulated current refers to the constant current value in CC mode. By
default, the load's regulated current is 0 A.
 In CC mode, when the set load current is greater than the current output from the
DUT, short circuit occurs to the DUT.
 In the setting command, the parameter "MINimum" indicates setting the load's
minimum regulated current; the parameter "MAXimum" indicates setting the load's
maximum regulated current; and the parameter "DEFault" indicates setting the load's
default regulated current.
 In the query command, the parameter "MINimum" indicates querying the minimum
value of the load's regulated current; the parameter "MAXimum" indicates querying
