Rigol DL3000 Programming Guide

Chapter 2 Command System RIGOL
DL3000 Programming Guide 2-29
Format
Example :SOUR:CURR:TRAN:ADUT 50 /*Sets the duty cycle in continuous mode to be 50%.*/
:SOUR:CURR:TRAN:ADUT? /*Queries the duty cycle set in continuous mode.*/
Related
Command
[:SOURce]:CURRent:TRANsient:AWIDth
[:SOURce]:VOLTage[:LEVel][:IMMediate]
Syntax [:SOURce]:VOLTage[:LEVel][:IMMediate] {<value>|MINimum|MAXimum|DEFault}
[:SOURce]:VOLTage[:LEVel][:IMMediate]? [MINimum|MAXimum|DEFault]
Description Sets the load voltage in CV mode.
Queries the load voltage set in CV mode.
Remarks  The load voltage refers to the constant voltage in CV mode. The unit is V.
 In CV mode, when the set load voltage is greater than the voltage output from the
DUT, open circuit occurs to the DUT.
 In the setting command, the parameter "MINimum" indicates setting the minimum
load voltage; the parameter "MAXimum" indicates setting the maximum load voltage;
and the parameter "DEFault" indicates setting the default load voltage.
 In the query command, the parameter "MINimum" indicates querying the minimum
load voltage; the parameter "MAXimum" indicates querying the maximum load
voltage; and the parameter "DEFault" indicates querying the default load voltage.
Return
Format
The query returns a real number.
Example
:SOUR:VOLT:LEV:IMM 5 /*Sets the load voltage in CV mode to be 5 V.*/
:SOUR:VOLT:LEV:IMM? /*Queries the load voltage set in CV mode.*/
[:SOURce]:VOLTage:RANGe
Syntax [:SOURce]:VOLTage:RANGe {<value>|MINimum|MAXimum|DEFault}
[:SOURce]:VOLTage:RANGe? [MINimum|MAXimum|DEFault]
Description Sets the voltage range in CV mode to be a high range or a low one.
Queries the voltage range set in CV mode.
Remarks  The default range is a high range.
 In the setting command, the parameter "MINimum" indicates setting a low range; the
parameter "MAXimum" indicates setting a high range; and the parameter "DEFault"
indicates setting the default range.
 In the query command, the parameter "MINimum" indicates querying a low range;
the parameter "MAXimum" indicates querying a high range; and the parameter
"DEFault" indicates querying the default range.
Return
Format
The query returns a real number.
Example
:SOUR:VOLT:RANG 150 /*Sets the voltage range in CV mode to be 150 V (a high range).*/
:SOUR:VOLT:RANG? /*Queries the voltage range set in CV mode.*/
