Rigol DL3000 Programming Guide

Chapter 2 Command System RIGOL
DL3000 Programming Guide 2-23
[:SOURce]:CURRent:SLEW:POSitive
Syntax [:SOURce]:CURRent:SLEW:POSitive {<value>|MINimum|MAXimum|DEFault}
[:SOURce]:CURRent:SLEW:POSitive? [MINimum|MAXimum|DEFault]
Description Sets the rising rate in transient operation mode.
Queries the rising rate set in transient operation mode.
Remarks  The rising rate of the load set in transient operation mode is the slew rate of the load
in transient operation mode. Its unit is A/μs.
 In the setting command, the parameter "MINimum" indicates setting the minimum
rising rate; the parameter "MAXimum" indicates setting the maximum rising rate; and
the parameter "DEFault" indicates setting the default rising rate.
 In the query command, the parameter "MINimum" indicates querying the minimum
rising rate; the parameter "MAXimum" indicates querying the maximum rising rate;
and the parameter "DEFault" indicates querying the default rising rate.
Return
Format
The query returns a real number.
Example :SOUR:CURR:SLEW:POS 0.5 /*Sets the rising rate in continuous mode to be 0.5 A/μs.*/
:SOUR:CURR:SLEW:POS? /*Queries the rising rate in continuous mode.*/
Related
Command
[:SOURce]:CURRent:SLEW:NEGative
[:SOURce]:CURRent:SLEW:NEGative
Syntax [:SOURce]:CURRent:SLEW:NEGative {<value>|MINimum|MAXimum|DEFault}
[:SOURce]:CURRent:SLEW:NEGative? [MINimum|MAXimum|DEFault]
Description Sets the falling rate in transient operation mode.
Queries the falling rate set in transient operation mode.
Remarks  The rising rate of the load set in continuous mode is the slew rate of the load in
continuous mode. Its unit is A/
μs.
 In the setting command, the parameter "MINimum" indicates setting the minimum
falling rate; the parameter "MAXimum" indicates setting the maximum falling rate;
and the parameter "DEFault" indicates setting the default falling rate.
 In the query command, the parameter "MINimum" indicates querying the minimum
falling rate; the parameter "MAXimum" indicates querying the maximum falling rate;
and the parameter "DEFault" indicates querying the default falling rate.
Return
Format
The query returns a real number.
Example :SOUR:CURR:SLEW:NEG 0.5 /*Sets the falling rate in continuous mode to be 0.5 A/μs.*/
:SOUR:CURR:SLEW:NEG? /*Queries the falling rate in continuous mode.*/
Related
Command
[:SOURce]:CURRent:SLEW:POSitive
