Chapter 2 Command System RIGOL

DL3000 Programming Guide 2-49

Command

[:SOURce]:FUNCtion:MODE

[:SOURce]:WAVe:TSTep

Syntax [:SOURce]:WAVe:TSTep{1|10}

[:SOURce]:WAVe: TSTep?

Description Sets the time step scale in the waveform display interface.

Queries the set time step scale.

Remarks  The time step scale includes *1 and *10. When the time step is set to "*1", it

indicates that the window time increases or decreases with a step size of 1; when the

time step is set to "*10", it indicates that the window time increases or decreases

with a step size of 10.

 When the window time unit is s, the time step scale *1 is not supported.

Return

Format

1 or 10

Example :SOUR:WAV:TST 1 /*Sets the time step scale in the waveform display interface to *1.*/

:SOUR:WAV:TST? /*Queries the set time step scale.*/

Command

[:SOURce]:FUNCtion:MODE

[:SOURce]:SENSe

Syntax [:SOURce]:SENSe {0|1|ON|OFF}

[:SOURce]:SENSe?

Description Enables or disables the Sense function of the electronic load.

Queries the on/off status of the Sense function of the electronic load.

Remarks  If the Sense function is enabled and the Sense terminal is not connected to the output

terminal of the DUT, then the electronic load is unable to accurately measure the

voltage on the terminal under any functions.

 The Sense function can be enabled or disabled in any working mode.

Return

Format

0 (OFF) or 1 (ON)

Example :SOUR:SENS 1 /* Enables the Sense function of the electronic load.*/

:SOUR:SENS? /*Queries the on/off status of the Sense function of the electronic load.*/
