RIGOL
User’s Guide for DM3058
2-66
3. Beeper On/Off
Press  Sys  Sound, enter the menu shown below:
Figure 2-87 Sound settings
4. Set Number Format
Press  System  Format to enter into following Manu to setup.
Figure 2-88 Set Number Format
Table 2-34 Function Menu for setting Number Format
Function
Menu
Setting
Explanation
Decimi
Expresses radix point with or .
Separate
No
Space
Expresses separator with , space
or none.
Save all the changes and go back to
last Manu
Take a parameter of AC Current as example, if you select Decimal as “ ”and List
Separator as “ ”, then it will shown according to the following format.
Figure 2-89 Date format
Decimal and Separator cannot be selected as the same format, that is if the
Decimal is , then the Separator can only be selected as “No” or “Space”. So
there are five different types of way totally to show Number Format by DM3058.
