Rigol DM3058 User Manual

RIGOL
User’s Guide for DM3058
VII
DM3058 Digital Multimeter Overview
RIGOL DM3058 is an instrument especially designed for high-precision,
multifunction, and automation measurements. It realized a combination of basic
measurement function and multifold math functions as well as Random Sensor
measurement function.
The DM3058 holds a high-resolution monochrome LCD display system with clear
keyboard layout and operation hints to make it easier and agility to use. Besides, it
can support multi-interface such as RS-232, USB, LAN and GPIB also for U-disk.
Meanwhile, you can also operate it at will via Virtual Terminal Display and Control
as well as Remote Network Access.
From the performance and characteristics given below, you will understand how a
DM3058 satisfy your measurement requirements.
 Rear 5 ½ digits resolution.
 Measurement speed: 2.5, 20 and 120 reading/s.
 Double Display function enables to display two types of characteristic for one
signal synchronously.
 Preset and Ordinary dual mode directly switch. Preset mode enable to stored
configuration quickly.
 Three types of way for setting Power Supply: Power on, Default, Switch.
 Measuring Speed: 2.5reading/s, 20reading/s and 120reading/s.
 DC Voltage Range between 200mV and 1000V.
 DC Current Range between 200uA and 10A.
 True-RMS, AC Voltage Range between 200mV and 750V.
 True-RMS, AC Voltage Current between20mA and 10A.
 Resistance Range between 200Ω and 100MΩ, 2, 4 Wire Resistance
Measurement.
 Capacitance Range between 2nF and 10000uF.
 Frequency Range between 20Hz and 1MHz.
 Continuity and Diode Test.
 Random Sensor Measurement function，Built-in Thermocouple compensate in
Cold Terminal.
 Abundant Math operations ： Max, Min, Average, P/F, dBm, dB, Relative
Measurement, Standard Deviation and Vertical chart.

Rigol DM3058 Specifications

General

Diode test	Yes
Product type	Digital multimeter
Frequency range	0.02 - 1000 kHz
AC current range	0.02 - 10 A
AC voltage range	0.2 - 750 V
DC current range	0.0002 - 10 A
DC voltage range	0.2 - 1000 V
Resistance range	200 - 100000000 Ω
Capacitance range	2 - 10000000 nF
Measuring category	CAT III 300V
Basic accuracy (frequency)	0.01 + 0.003
Basic accuracy (DC current)	0.055 + 0.005
Basic accuracy (DC voltage)	0.015 + 0.003
Basic accuracy (resistance)	0.020 + 0.003
Basic accuracy (capacitance)	1 + 0.5
Display digits	5.5 digits
Display size (HxV)	256 x 64 mm
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	107 mm
Width	231.6 mm
Height	290.5 mm
Weight	2500 g
