Rigol DS1054Z Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-91
:MATH:SOURce1
Syntax
:MATH:SOURce1 <src>
:MATH:SOURce1?
Description
Set or query the source or source A of algebraic operation/functional operation/the outer
layer operation of compound operation.
Parameter
Name
Type
Range
Default
<src>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4|FX}
CHANnel1
Explanation
 For algebraic operations, this command is used to set source A.
 For functional operations, only this command is used to set the source.
 For compound operations, this command is used to set source A of the outer layer
operation when the outer layer operation is algeriac operation and the range of
<src> is {CHANnel1|CHANnel2|CHANnel3|CHANnel4}; this command is used to set
the source of the outer layer operation when the outer layer operation is functional
operation and <src> can only be FX.
Note: When the outer layer operation of compound operation is algebraic operation, at least
one of source A and source B of the outer layer operation should be set to FX.
 When "FX" is selected, you can send
the :MATH:OPTion:FX:SOURce1, :MATH:OPTion:FX:SOURce2,
and :MATH:OPTion:FX:OPERator commands to set the sources and operator of the
inner layer operation.
Return
Format
The query returns CHAN1, CHAN2, CHAN3, CHAN4, or FX.
Example
:MATH:SOURce1 CHANnel3 /*Set source A of algebraic operation to CH3*/
:MATH:SOURce1? /*The query returns CHAN3*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
