Rigol DS1054Z Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-75
:FUNCtion:WREPlay:FEND
Syntax
:FUNCtion:WREPlay:FEND <end>
:FUNCtion:WREPlay:FEND?
Description
Set or query the end frame of waveform playback.
Parameter
Name
Type
Range
Default
<end>
Integer
1 to the maximum number of frames
recorded
The maximum number
of frames recorded
Explanation
 Use the :FUNCtion:WRECord:FEND command to set the maximum number of
frames recorded.
 The end frame of waveform playback cannot be lower than the start frame of
waveform playback (:FUNCtion:WREPlay:FSTart).
 You can only set the end frame of waveform playback when a waveform is currently
recorded.
 You cannot set the end frame of waveform playback during the waveform recording
or playback process.
Return
Format
The query returns an integer.
Example
:FUNCtion:WREPlay:FEND 4096 /*Set the end frame of waveform playback to
4096*/
:FUNCtion:WREPlay:FEND? /*The query returns 4096*/
:FUNCtion:WREPlay:FMAX?
Syntax
:FUNCtion:WREPlay:FMAX?
Description
Query theb maximum number of frames can be played, namely the maximum number of
frames recorded.
Explanation
Use the :FUNCtion:WRECord:FEND command to set the maximum number of frames
recorded.
Return
Format
The query returns an integer.

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
