Page #172 background imageLoading...
Page #172 background image
RIGOL Chapter 2 Command System
2-156 MSO1000Z/DS1000Z Programming Guide
Related
Commands
:TIMebase[:MAIN]:SCALe
:ACQuire:SRATe?
:TRIGger:MODE
:TIMebase[:MAIN]:OFFSet
Syntax
:TIMebase[:MAIN]:OFFSet <offset>
:TIMebase[:MAIN]:OFFSet?
Description
Set or query the main timebase offset. The default unit is s.
Parameter
Name
Type
Range
Default
<offset>
Real
Refer to Explanation
0
Explanation
The range of <offset> is related to the current mode of the horizontal
timebase (refer to :TIMebase:MODE) and run state of the oscilloscope.
YT mode
RUN: (-0.5 x MemDepth/SampleRate) to 1s (when the horizontal
timebase is less than 200ms/div)
(-0.5 x MemDepth/SampleRate) to (10 x MainScale) (when the
horizontal timebase is greater than or equal to 200ms/div, namely
the "Slow Sweep" mode)
STOP: (-MemDepth/SampleRate) to (1s + 0.5 x MemDepth/SampleRate)
Roll mode
RUN: This command is invalid.
STOP: (-12 x MainScale) to 0
Wherein, MemDepth is the current memory depth of the oscilloscope,
SampleRate is the current sample rate of the oscilloscope, and MainScale is the
current main timebase scale of the oscilloscope.
When the horizontal timebase mode is YT and the horizontal timebase is
200ms/div or larger (namely the "Slow Sweep" mode), this command is invalid
when the oscilloscope is in the transition to the "Stop" state.
Return Format
The query returns the main timebase offset in scientific notation.
Example
:TIMebase:MAIN:OFFSet 0.0002 /*Set the main timebase offset to 20ms*/
:TIMebase:MAIN:OFFSet? /*The query returns 2.0000000e-04*/
Related
Commands
:RUN
:STOP
:ACQuire:MDEPth
:ACQuire:SRATe?
:TIMebase[:MAIN]:SCALe
