RIGOL Chapter 2 Command System
2-42 MSO1000Z/DS1000Z Programming Guide
:DECoder<n>:CONFig:LINE
Syntax
:DECoder<n>:CONFig:LINE <bool>
:DECoder<n>:CONFig:LINE?
Description
Turn on or off the bus display function, or query the status of the bus display function.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<bool>
Bool
{{1|ON}|{0|OFF}}
1|ON
Explanation
When this function is enabled, the bus will be displayed on the screen. You can send
the :DECoder<n>:POSition command to adjust the vertical display position of the bus.
Return
Format
The query returns 1 or 0.
Example
:DECoder1:CONFig:LINE OFF /*Turn off the bus display function*/
:DECoder1:CONFig:LINE? /*The query returns 0*/
:DECoder<n>:CONFig:FORMat
Syntax
:DECoder<n>:CONFig:FORMat <bool>
:DECoder<n>:CONFig:FORMat?
Description
Turn on or off the format display function, or query the status of the format display
function.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<bool>
Bool
{{1|ON}|{0|OFF}}
1|ON
Explanation
When this function is turned on, the current bus display format will be displayed at the
right of the label display (when the bus display is turned on). You can send
the :DECoder<n>:FORMat command to set the bus display format.
Return
Format
The query returns 1 or 0.
Example
:DECoder1:CONFig:FORMat OFF /*Turn off the format display function*/
:DECoder1:CONFig:FORMat? /*The query returns 0*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
