Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-65
:DISPlay:GRADing:TIME
Syntax
:DISPlay:GRADing:TIME <time>
:DISPlay:GRADing:TIME?
Description
Set or query the persistence time. The default unit is s.
Parameter
Name
Type
Range
Default
<time>
Discrete
{MIN|0.1|0.2|0.5|1|5|10|INFinite}
MIN
Explanation
 MIN: set the persistence time to its minimum to view the waveform changing in high
refresh rate.
 Specific Values: set the persistence time to one of the values listed above to observe
glitch that changes relatively slowly or glitch with low occurrence probability.
 INFinite: in this mode, the oscilloscope displays the newly acquired waveform
without clearing the waveform formerly acquired. It can be used to measure noise
and jitter as well as capture incidental events.
Return
Format
The query returns MIN, 0.1, 0.2, 0.5, 1, 5, 10, or INF.
Example
:DISPlay:GRADing:TIME 0.1 /*Set the persistence time to 0.1s*/
:DISPlay:GRADing:TIME? /*The query returns 0.1*/
:DISPlay:WBRightness
Syntax
:DISPlay:WBRightness <time>
:DISPlay:WBRightness?
Description
Set or query the waveform brightness.
Parameter
Name
Type
Range
Default
<time>
Integer
0 to 100
60
Return
Format
The query returns an integer between 0 and 100.
Example
:DISPlay:WBRightness 50 /*Set the waveform brightness to 50%*/
:DISPlay:WBRightness? /*The query returns 50*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
