Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-67
:ETABle Commands
The :ETABle commands are used to set the parameters related to the decoding event table.
Command List:
 :ETABle<n>:DISP
 :ETABle<n>:FORMat
 :ETABle<n>:VIEW
 :ETABle<n>:COLumn
 :ETABle<n>:ROW
 :ETABle<n>:SORT
 :ETABle<n>:DATA?
:ETABle<n>:DISP
Syntax
:ETABle<n>:DISP <bool>
:ETABle<n>:DISP?
Description
Turn on or off the decoding event table, or query the status of the decoding event table.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<bool>
Bool
{{1|ON}|{0|OFF}}
0|OFF
Explanation
This command is only valid when the decoder is turned on (:DECoder<n>:DISPlay).
Return
Format
The query returns 1 or 0.
Example
:ETABle1:DISP ON /*Turn on the decoding event table*/
:ETABle1:DISP? /*The query returns 1*/
:ETABle<n>:FORMat
Syntax
:ETABle<n>:FORMat <fmt>
:ETABle<n>:FORMat?
Description
Set or query the data display format of the event table.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<fmt>
Discrete
{HEX|ASCii|DEC}
HEX
Return
Format
The query returns HEX, ASC, or DEC.
Example
:ETABle1:FORMat ASCii /*Set the data display format of the event table to ASCII*/
:ETABle1:FORMat? /*The query returns ASC*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
