Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-83
:LA:AUTosort
Syntax
:LA:AUTosort <n>
Description
Set the auto ordering mode of the waveforms of the channels turned on on the screen.
Parameter
Name
Type
Range
Default
<n>
Discrete
{0|1}
1
Explanation
 <n> = 0: waveforms on the screen are D15 to D0 from top to bottom
 <n> = 1: waveforms on the screen are D0 to D15 from top to bottom
:LA:DIGital<n>:DISPlay
Syntax
:LA:DIGital<n>:DISPlay <bool>
:LA:DIGital<n>:DISPlay?
Description
Turn on or off the specified digital channel, or query the status of the specified digital
channel.
Parameter
Name
Type
Range
Default
<n>
Integer
0 to 15
--
<bool>
Bool
{{1|ON}|{0|OFF}}
D0 to D7: 1|ON
D8 to D15: 0|OFF
Explanation
You can set the channels currently turned on as the active channel using the :LA:ACTive
command.
Return
Format
The query returns 1 or 0.
Example
:LA:DIGital3:DISPlay ON /*Turn D3 on*/
:LA:DIGital3:DISPlay? /*The query returns 1*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
