RIGOL Chapter 2 Command System
2-136 MSO1000Z/DS1000Z Programming Guide
[:SOURce[<n>]]:MOD[:STATe]
Syntax
[:SOURce[<n>]]:MOD[:STATe] <bool>
[:SOURce[<n>]]:MOD[:STATe]?
Description
Enable or disable the modulation of the specified source channel, or query the status of
the modulation of the specified source channel.
Parameter
Name
Type
Range
Default
[<n>]
Discrete
{1|2}
If omitted, the operation is
performed on source 1 by default
<bool>
Bool
{{1|ON}|{0|OFF}}
0|OFF
Explanation
 The signal source of MSO1000Z/DS1000Z provides amplitude modulation (AM) and
frequency modulation (FM) which can be selected by sending the
[:SOURce[<n>]]:MOD:TYPe command.
 Sine, Square, Ramp, Built-in waveforms, or Arb waveform (except DC) can be used
as the carrier waveform.
 You can use the [:SOURce[<n>]]:MOD:AM:INTernal:FUNCtion or
[:SOURce[<n>]]:MOD:FM:INTernal:FUNCtion command to selelct Sine, Square,
Triangle, or Noise as the modulating waveform.
Return
Format
The query returns OFF or ON.
Example
:MOD ON /*Enable the modulation of source 1*/
:MOD? /*The query returns ON*/
Related
Command
[:SOURce[<n>]]:FUNCtion[:SHAPe]
[:SOURce[<n>]]:MOD:TYPe
Syntax
[:SOURce[<n>]]:MOD:TYPe <type>
[:SOURce[<n>]]:MOD:TYPe?
Description
Set or query the modulation type of the specified source channel.
Parameter
Name
Type
Range
Default
[<n>]
Discrete
{1|2}
If omitted, the operation is
performed on source 1 by default
<type>
Discrete
{AM|FM}
AM
Explanation
 AM: amplitude modulation. The amplitude of the carrier waveform varies with the
amplitude of the modulating waveform.
FM: frequency modulation. The frequency of the carrier waveform varies with the
amplitude of the modulating waveform.
 Sine, Square, Ramp, Built-in waveforms, or Arb waveform (except DC) can be used
as the carrier waveform.
 You can use the [:SOURce[<n>]]:MOD:AM:INTernal:FUNCtion or
[:SOURce[<n>]]:MOD:FM:INTernal:FUNCtion command to selelct Sine, Square,
Triangle, or Noise as the modulating waveform.
Return
Format
The query returns AM or FM.
Example
:MOD:TYPe AM /*Set the modulation type of source 1 to AM*/
:MOD:TYPe? /*The query returns AM*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
