Rigol DS1054Z Programming Guide

RIGOL Chapter 2 Command System
2-126 MSO1000Z/DS1000Z Programming Guide
:REFerence Commands
The :REFerence commands are used to set the reference waveform parameters.
Command List:
 :REFerence:DISPlay
 :REFerence<n>:ENABle
 :REFerence<n>:SOURce
 :REFerence<n>:VSCale
 :REFerence<n>:VOFFset
 :REFerence<n>:RESet
 :REFerence<n>:CURRent
 :REFerence<n>:SAVe
 :REFerence<n>:COLor
:REFerence:DISPlay
Syntax
:REFerence:DISPlay <bool>
:REFerence:DISPlay?
Description
Enable or disable the REF function, or query the status of the REF function.
Parameter
Name
Type
Range
Default
<bool>
Bool
{{1|ON}|{0|OFF}}
0|OFF
Return
Format
The query returns 1 or 0.
Example
:REFerence:DISPlay ON /*Enable the REF function*/
:REFerence:DISPlay? /*The query returns 1*/
:REFerence<n>:ENABle
Syntax
:REFerence<n>:ENABle <bool>
:REFerence<n>:ENABle?
Description
Enable or disable the specified reference channel, or query the status of the specified
reference channel.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4|5|6|7|8|9|10}
1
<bool>
Bool
{{1|ON}|{0|OFF}}
Ref1: 1|ON
Others: 0|OFF
Return
Format
The query returns 1 or 0.
Example
:REFerence1:ENABle ON /*Enable reference channel 1*/
:REFerence1:ENABle? /*The query returns 1*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
