:TRIGger Commands
The :TRIGger commands are used to set the trigger system of the oscilloscope.
Command List:
 :TRIGger:MODE
 :TRIGger:COUPling
 :TRIGger:STATus?
 :TRIGger:SWEep
 :TRIGger:HOLDoff
 :TRIGger:NREJect
 :TRIGger:POSition?
 :TRIGger:EDGe
 :TRIGger:PULSe
 :TRIGger:SLOPe
 :TRIGger:VIDeo
 :TRIGger:PATTern
 :TRIGger:DURATion
 :TRIGger:TIMeout
 :TRIGger:RUNT
 :TRIGger:WINDows
 :TRIGger:DELay
 :TRIGger:SHOLd
 :TRIGger:NEDGe
 :TRIGger:RS232
 :TRIGger:IIC
 :TRIGger:SPI
:TRIGger:MODE
Syntax
:TRIGger:MODE <mode>
:TRIGger:MODE?
Description
Select or query the trigger type.
Parameter
Name
Type
Range
Default
<mode>
Discrete
{EDGE|PULSe|RUNT|WIND|NEDG|SLOPe|VIDeo|
PATTern|DELay|TIMeout|DURation|SHOLd|
RS232|IIC|SPI}
EDGE
Return
Format
The query returns EDGE, PULS, RUNT, WIND, NEDG, SLOP, VID, PATT, DEL, TIM, DUR,
SHOL, RS232, IIC, or SPI.
Example
:TRIGger:MODE SLOPe /*Select slope trigger*/
:TRIGger:MODE? /*The query returns SLOP*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
