Rigol DS1054Z Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-153
:TIMebase Commands
The :TIMebase commands are used to set the horizontal parameters, such as enabling the delayed sweep
and setting the horizontal timebase mode.
Command List:
 :TIMebase:DELay:ENABle
 :TIMebase:DELay:OFFSet
 :TIMebase:DELay:SCALe
 :TIMebase[:MAIN]:OFFSet
 :TIMebase[:MAIN]:SCALe
 :TIMebase:MODE
:TIMebase:DELay:ENABle
Syntax
:TIMebase:DELay:ENABle <bool>
:TIMebase:DELay:ENABle?
Description
Enable or disable the delayed sweep, or query the status of the delayed sweep.
Parameter
Name
Type
Range
Default
<bool>
Bool
{{1|ON}|{0|OFF}}
0|OFF
Explanation
Delayed sweep can be used to enlarge a length of waveform horizontally to view
waveform details.
Return Format
The query returns 1 or 0.
Example
:TIMebase:DELay:ENABle ON /*Enable the delayed sweep*/
:TIMebase:DELay:ENABle? /*The query returns 1*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
