Rigol DS1054Z Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-157
:TIMebase[:MAIN]:SCALe
Syntax
:TIMebase[:MAIN]:SCALe <scale>
:TIMebase[:MAIN]:SCALe?
Description
Set or query the main timebase scale. The default unit is s/div.
Parameter
Name
Type
Range
Default
<scale>
Real
YT mode: 5ns/div to 50s/div in 1-2-5 step
Roll mode: 200ms/div to 50s/div in 1-2-5 step
1μs/div
Explanation
When the horizontal timebase mode is YT and the horizontal timebase is 200ms/div
or larger (namely the "Slow Sweep" mode), this command is invalid when the
oscilloscope is in the transition to the "Stop" state.
Return Format
The query returns the main timebase scale in scientific notation.
Example
:TIMebase:MAIN:SCALe 0.0002 /*Set the main timebase scale to 200μs/div*/
:TIMebase:MAIN:SCALe? /*The query returns 2.0000000e-04*/
Related
Command
:TIMebase:MODE
:TIMebase:MODE
Syntax
:TIMebase:MODE <mode>
:TIMebase:MODE?
Description
Set or query the mode of the horizontal timebase.
Parameter
Name
Type
Range
Default
<mode>
Discrete
{MAIN|XY|ROLL}
MAIN
Explanation
 MAIN: YT mode
 XY: XY mode
 ROLL: Roll mode
Return Format
The query returns MAIN, XY, or ROLL.
Example
:TIMebase:MODE XY /*Set the horizontal timebase mode to XY*/
:TIMebase:MODE? /*The query returns XY*/
Related
Commands
:TIMebase:DELay:OFFSet
:TIMebase:DELay:SCALe
:TIMebase[:MAIN]:OFFSet
:TIMebase[:MAIN]:SCALe

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
