Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-129
:REFerence<n>:SAVe
Syntax
:REFerence<n>:SAVe
Description
Store the waveform of the current reference channel to the internal memory as
reference waveform.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4|5|6|7|8|9|10}
--
Related
Command
:REFerence<n>:CURRent
:REFerence<n>:COLor
Syntax
:REFerence<n>:COLor <color>
:REFerence<n>:COLor?
Description
Set or query the display color of the current reference channel.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4|5|6|7|8|9|10}
--
<color>
Discrete
{GRAY|GREEn|LBLue|MAGenta|ORANge}
GRAY
Return Format
The query returns GRAY, GREE, LBL, MAG, or ORAN.
Example
:REFerence1:COLor GREEn /*Set the display color of reference channel 1 (the
current reference channel) to GREEn*/
:REFerence1:COLor? /*The query returns GREE*/
Related
Command
:REFerence<n>:CURRent

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
