Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-9
:CHANnel<n> Commands
The :CHANnel<n> commands are used to set or query the vertical system parameters of the analog
channels, such as the bandwidth limit, coupling, vertical scale, and vertical offset.
Command List:
 :CHANnel<n>:BWLimit
 :CHANnel<n>:COUPling
 :CHANnel<n>:DISPlay
 :CHANnel<n>:INVert
 :CHANnel<n>:OFFSet
 :CHANnel<n>:RANGe
 :CHANnel<n>:TCAL
 :CHANnel<n>:SCALe
 :CHANnel<n>:PROBe
 :CHANnel<n>:UNITs
 :CHANnel<n>:VERNier
:CHANnel<n>:BWLimit
Syntax
:CHANnel<n>:BWLimit <type>
:CHANnel<n>:BWLimit?
Description
Set or query the bandwidth limit parameter of the specified channel.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
--
<type>
Discrete
{20M|OFF}
OFF
Explanation
 OFF: disable the bandwidth limit and the high frequency components of the signal
under test can pass the channel.
20M: enable the bandwidth limit and the high frequency components of the signal
under test that exceed 20 MHz are attenuated.
 Enabling the bandwidth limit can reduce the noise, but can also attenuate the high
frequency components.
Return
Format
The query returns 20M or OFF.
Example
:CHANnel1:BWLimit 20M /*Enable the 20MHz bandwidth limit*/
:CHANnel1:BWLimit? /*The query returns 20M*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
