Rigol DS1054Z Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-179
:TRIGger:DURATion
Command List:
 :TRIGger:DURATion:SOURce
 :TRIGger:DURATion:TYPe
 :TRIGger:DURATion:WHEN
 :TRIGger:DURATion:TUPPer
 :TRIGger:DURATion:TLOWer
:TRIGger:DURATion:SOURce
Syntax
:TRIGger:DURATion:SOURce <source>
:TRIGger:DURATion:SOURce?
Description
Set or query the trigger source in duration trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|
D9|D10|D11|D12|D13|D14|D15|
CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Explanation
When one or more of channels D0 to D7 is turned on, CH4 cannot be selected; when one
or more of D8 to D15 is turned on, CH3 cannot be selected.
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:TRIGger:DURATion:SOURce CHANnel2 /*Set the trigger source to CH2*/
:TRIGger:DURATion:SOURce? /*The query returns CHAN2*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
