:MEASure:ITEM
Syntax
:MEASure:ITEM <item>[,<src>[,<src>]]
:MEASure:ITEM? <item>[,<src>[,<src>]]
Description
Measure any waveform parameter of the specified source, or query the measurement
result of any waveform parameter of the specified source.
Parameter
Name
Type
Range
Default
<item>
Discrete
{VMAX|VMIN|VPP|VTOP|VBASe|VAMP|VAVG|
VRMS|OVERshoot|PREShoot|MARea|MPARea|
PERiod|FREQuency|RTIMe|FTIMe|PWIDth|
NWIDth|PDUTy|NDUTy|RDELay|FDELay|
RPHase|FPHase|TVMAX|TVMIN|PSLEWrate|
NSLEWrate|VUPper|VMID|VLOWer|VARIance|
PVRMS|PPULses|NPULses|PEDGes|NEDGes}
--
<src>
Discrete
Refer to Explanation
Explanation
 [,<src>[,<src>]] sets the source of the parameter to be measured.
 When <item> is PERiod, FREQuency, PWIDth, NWIDth, PDUTy, NDUTy, RDELay,
FDELay, RPHase, or FPHase, the range of <src> is
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11|D12|D13|D14|D15|CHANnel1|CHAN
nel2|CHANnel3|CHANnel4|MATH}.
When <item> is any of other measurement parameters, the range of <src> is
{CHANnel1|CHANnel2|CHANnel3|CHANnel4|MATH}.
 If the parameter to be measured only needs a single source (VMAX, VMIN, VPP,
VTOP, VBASe, VAMP, VAVG, VRMS, OVERshoot, MARea, MPARea, PREShoot, PERiod,
FREQuency, RTIMe, FTIMe, PWIDth, NWIDth, PDUTy, NDUTy, TVMAX, TVMIN,
PSLEWrate, NSLEWrate, VUPper, VMID, VLOWer, VARIance, PVRMS, PPULses,
NPULses, PEDGes, and NEDGes), you only need to set a single source. If
[,<src>[,<src>]] is omitted, the source is the one selected by the :MEASure:SOURce
command by default.
 If the parameter to be measured needs two sources (RDELay, FDELay, RPHase, and
FPHase), the command needs to include two sources; otherwise, the command is
invalid. If [,<src>[,<src>]] is omitted, the sources are the ones selected by
the :MEASure:SETup:DSA and :MEASure:SETup:DSB or :MEASure:SETup:PSA
and :MEASure:SETup:PSB commands by default.
Return
Format
The query returns the measurement result in scientific notation.
Example
:MEASure:ITEM OVERshoot,CHANnel2 /*Enable the overshoot measurement of CH2*/
:MEASure:ITEM? OVERshoot,CHANnel2 /*The query returns 8.888889e-03*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
