RIGOL Chapter 2 Command System
2-76 MSO1000Z/DS1000Z Programming Guide
:FUNCtion:WREPlay:FINTerval
Syntax
:FUNCtion:WREPlay:FINTerval <interval>
:FUNCtion:WREPlay:FINTerval?
Description
Set or query the time interval between frames in waveform playback. The default unit is
s.
Parameter
Name
Type
Range
Default
<interval>
Real
100ns to 10s
100ns
Explanation
 You can only set the time interval of waveform playback when a waveform is
currently recorded.
 You cannot set the time interval of waveform playback during the waveform
recording or playback process.
Return
Format
The query returns the current time interval in scientific notation.
Example
:FUNCtion:WREPlay:FINTerval 0.001 /*Set the time interval to 1ms*/
:FUNCtion:WREPlay:FINTerval? /*The query returns 1.000000e-03*/
:FUNCtion:WREPlay:MODE
Syntax
:FUNCtion:WREPlay:MODE <mode>
:FUNCtion:WREPlay:MODE?
Description
Set or query the waveform playback mode.
Parameter
Name
Type
Range
Default
<mode>
Discrete
{REPeat|SINGle}
SINGle
Explanation
 REPeat: cycle playback. Play from the start frame to the end frame and then repeat
until you stop it manually.
 SINGle: single playback. Play from the start frame to the end frame and then stop.
 You can only set the waveform playback mode when a waveform is currently
recorded.
 You cannot set the waveform playback mode during the waveform recording or
playback process.
Return
Format
The query returns REP or SING.
Example
:FUNCtion:WREPlay:MODE REPeat /*Set the waveform playback mode to cycle*/
:FUNCtion:WREPlay:MODE? /*The query returns REP*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
