Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-111
:MASK:CREate
Syntax
:MASK:CREate
Description
Create the pass/fail test mask using the current horizontal adjustment parameter and
vertical adjustment parameter.
Explanation
This command is valid only when the pass/fail test is enabled (:MASK:ENABle) and is not
in the run state (:MASK:OPERate).
Related
Commands
:MASK:X
:MASK:Y
:MASK:PASSed?
Syntax
:MASK:PASSed?
Description
Query the number of passed frames in the pass/fail test.
Return
Format
The query returns an integer.
:MASK:FAILed?
Syntax
:MASK:FAILed?
Description
Query the number of failed frames in the pass/fail test.
Return
Format
The query returns an integer.
:MASK:TOTal?
Syntax
:MASK:TOTal?
Description
Query the total number of frames in the pass/fail test.
Return
Format
The query returns an integer.
:MASK:RESet
Syntax
:MASK:RESet
Description
Reset the numbers of passed frames and failed frames as well as the total number of
frames in the pass/fail test to 0.
Related
Commands
:MASK:PASSed?
:MASK:FAILed?
:MASK:TOTal?

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
