Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-33
:CURSor:XY
The :CURSor:XY commands can only be used when the horizontal timebase mode is XY.
Command List:
 :CURSor:XY:AX
 :CURSor:XY:BX
 :CURSor:XY:AY
 :CURSor:XY:BY
 :CURSor:XY:AXValue?
 :CURSor:XY:AYValue?
 :CURSor:XY:BXValue?
 :CURSor:XY:BYValue?
:CURSor:XY:AX
Syntax
:CURSor:XY:AX <x>
:CURSor:XY:AX?
Description
Set or query the horizontal position of cursor A in the XY cursor measurement mode.
Parameter
Name
Type
Range
Default
<x>
Integer
5 to 394
100
Explanation
In the XY timebase mode, the horizontal and vertical positions of the cursor are defined
by the pixel coordinate of the XY display area. The pixel coordinate of the screen ranges
from (0,0) to (400,400). Wherein, (0,0) is located at the right top corner and (400,400) is
located at the left bottom corner. The horizontal and vertical pixel ranges are both from 0
to 400.
Return
Format
The query returns an integer between 5 and 394.
Example
:CURSor:XY:AX 200 /*Set the horizontal position of cursor A to 200*/
:CURSor:XY:AX? /*The query returns 200*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
