Rigol DS1054Z Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-35
:CURSor:XY:BY
Syntax
:CURSor:XY:BY <y>
:CURSor:XY:BY?
Description
Set or query the vertical position of cursor B in the XY cursor measurement mode.
Parameter
Name
Type
Range
Default
<x>
Integer
5 to 394
300
Explanation
In the XY timebase mode, the horizontal and vertical positions are defined by the pixel
coordinate of the XY display area. The pixel coordinate of the XY display area ranges from
(0,0) to (400,400). Wherein, (0,0) is located at the right top corner and (400,400) is
located at the left bottom corner. The horizontal and vertical pixel ranges are both from 0
to 400.
Return
Format
The query returns an integer between 5 and 394.
Example
:CURSor:XY:BY 200 /*Set the vertical position of cursor B to 200*/
:CURSor:XY:BY? /*The query returns 200*/
:CURSor:XY:AXValue?
Syntax
:CURSor:XY:AXValue?
Description
Query the X value of cursor A in the XY cursor measurement mode. The unit depends on
the amplitude unit of the corresponding channel.
Return
Format
The query returns the X value of cursor A in scientific notation.
Example
:CURSor:XY:AXValue? /*The query returns 2.000000e+00*/
Related
Command
:CHANnel<n>:UNITs
:CURSor:XY:AYValue?
Syntax
:CURSor:XY:AYValue?
Description
Query the Y value of cursor A in the XY cursor measurement mode. The unit depends on
the amplitude unit of the corresponding channel.
Return
Format
The query returns the Y value of cursor A in scientific notation.
Example
:CURSor:XY:AYValue? /*The query returns 2.000000e+00*/
Related
Command
:CHANnel<n>:UNITs

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
