Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-39
:DECoder<n>:POSition
Syntax
:DECoder<n>:POSition <pos>
:DECoder<n>:POSition?
Description
Set or query the vertical position of the bus on the screen.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<pos>
Integer
50 to 350
Decoder 1: 350
Decoder 2: 300
Explanation
The screen is divided into 400 parts vertically which are marked as 0 to 400 from top to
bottom respectively. The range of <pos> is from 50 to 350.
Return
Format
The query returns an integer between 50 and 350.
Example
:DECoder1:POSition 300 /*Set the vertical position of the bus to 300*/
:DECoder1:POSition? /*The query returns 300*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
