RIGOL Chapter 2 Command System
2-196 MSO1000Z/DS1000Z Programming Guide
:TRIGger:SHOLd
Command List:
 :TRIGger:SHOLd:DSrc
 :TRIGger:SHOLd:CSrc
 :TRIGger:SHOLd:SLOPe
 :TRIGger:SHOLd:PATTern
 :TRIGger:SHOLd:TYPe
 :TRIGger:SHOLd:STIMe
 :TRIGger:SHOLd:HTIMe
:TRIGger:SHOLd:DSrc
Syntax
:TRIGger:SHOLd:DSrc <source>
:TRIGger:SHOLd:DSrc?
Description
Set or query the data source in setup/hold trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:TRIGger:SHOLd:DSrc CHANnel1 /*Set the data source to CH1*/
:TRIGger:SHOLd:DSrc? /*The query returns CHAN1*/
:TRIGger:SHOLd:CSrc
Syntax
:TRIGger:SHOLd:CSrc <source>
:TRIGger:SHOLd:CSrc?
Description
Set or query the clock source in setup/hold trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel2
Return
Format
The query returns CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:TRIGger:SHOLd:CSrc CHANnel2 /*Set the clock source to CH2*/
:TRIGger:SHOLd:CSrc? /*The query returns CHAN2*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
