Rigol DS1054Z Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-197
:TRIGger:SHOLd:SLOPe
Syntax
:TRIGger:SHOLd:SLOPe <slope>
:TRIGger:SHOLd:SLOPe?
Description
Set or query the edge type in setup/hold trigger.
Parameter
Name
Type
Range
Default
<slope>
Discrete
{POSitive|NEGative}
POSitive
Return
Format
The query returns POS or NEG.
Example
:TRIGger:SHOLd:SLOPe NEGative /*Set the edge type to falling edge*/
:TRIGger:SHOLd:SLOPe? /*The query returns NEG*/
:TRIGger:SHOLd:PATTern
Syntax
:TRIGger:SHOLd:PATTern <pattern>
:TRIGger:SHOLd:PATTern?
Description
Set or query the data type in setup/hold trigger.
Parameter
Name
Type
Range
Default
<pattern>
Discrete
{H|L}
H
Explanation
H: high level
L: low level
Return
Format
The query returns H or L.
Example
:TRIGger:SHOLd:PATTern L /*Set the data type to L*/
:TRIGger:SHOLd:PATTern? /*The query returns L*/
:TRIGger:SHOLd:TYPe
Syntax
:TRIGger:SHOLd:TYPe <type>
:TRIGger:SHOLd:TYPe?
Description
Set or query the setup type in setup/hold trigger.
Parameter
Name
Type
Range
Default
<type>
Discrete
{SETup|HOLd|SETHOLd}
SETup
Explanation
 SETup: the oscilloscope triggers when the setup time is less than the setting value
(:TRIGger:SHOLd:STIMe).
 HOLd: the oscilloscope triggers when the hold time is less than the setting value
(:TRIGger:SHOLd:HTIMe).
 SETHOLd: the oscilloscope triggers when the setup time or hold time is less than the
corresponding setting value (:TRIGger:SHOLd:STIMe or :TRIGger:SHOLd:HTIMe).
Return
Format
The query returns SET, HOL, or SETHOL.
Example
:TRIGger:SHOLd:TYPe SETHOLd /*Set the setup type to setup&hold*/
:TRIGger:SHOLd:TYPe? /*The query returns SETHOL*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
