Rigol DS1054Z Programming Guide

RIGOL Chapter 2 Command System
2-198 MSO1000Z/DS1000Z Programming Guide
:TRIGger:SHOLd:STIMe
Syntax
:TRIGger:SHOLd:STIMe <NR3>
:TRIGger:SHOLd:STIMe?
Description
Set or query the setup time in setup/hold trigger. The default unit is s.
Parameter
Name
Type
Range
Default
<NR3>
Real
8ns to 1s
1μs
Explanation
 Setup time refers to the period of time that the data stays stable and constant before
the clock signal of the trigger appears.
 This command is only available when the setup type (refer to :TRIGger:SHOLd:TYPe)
is SETup or SETHOLd.
Return
Format
The query returns the setup time in scientific notation.
Example
:TRIGger:SHOLd:STIMe 0.002 /*Set the setup time to 2ms*/
:TRIGger:SHOLd:STIMe? /*The query returns 2.000000e-03*/
Related
Command
:TRIGger:SHOLd:HTIMe
:TRIGger:SHOLd:HTIMe
Syntax
:TRIGger:SHOLd:HTIMe <NR3>
:TRIGger:SHOLd:HTIMe?
Description
Set or query the hold time in setup/hold trigger. The default unit is s.
Parameter
Name
Type
Range
Default
<NR3>
Real
8ns to 1s
1μs
Explanation
 Hold time refers to the period of time that the data stays stable and constant after
the clock signal of the trigger appears.
 This command is only available when the setup type (refer to :TRIGger:SHOLd:TYPe)
is HOLd or SETHOLd.
Return
Format
The query returns the hold time in scientific notation.
Example
:TRIGger:SHOLd:HTIMe 0.002 /*Set the hold time to 2ms*/
:TRIGger:SHOLd:HTIMe? /*The query returns 2.000000e-03*/
Related
Command
:TRIGger:SHOLd:STIMe

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
