Rigol DS1054Z Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-189
:TRIGger:WINDows
Command List:
 :TRIGger:WINDows:SOURce
 :TRIGger:WINDows:SLOPe
 :TRIGger:WINDows:POSition
 :TRIGger:WINDows:TIMe
 :TRIGger:WINDows:ALEVel
 :TRIGger:WINDows:BLEVel
:TRIGger:WINDows:SOURce
Syntax
:TRIGger:WINDows:SOURce <source>
:TRIGger:WINDows:SOURce?
Description
Set or query the trigger source in windows trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:TRIGger:WINDows:SOURce CHANnel2 /*Set the trigger source to CH2*/
:TRIGger:WINDows:SOURce? /*The query returns CHAN2*/
:TRIGger:WINDows:SLOPe
Syntax
:TRIGger:WINDows:SLOPe <type>
:TRIGger:WINDows:SLOPe?
Description
Set or query the windows type in windows trigger.
Parameter
Name
Type
Range
Default
<type>
Discrete
{POSitive|NEGative|RFALl}
POSitive
Explanation
 POSitive: trigger on the rising edge of the input signal when the voltage level is
greater than the preset high trigger level.
 NEGative: trigger on the falling edge of the input signal when the voltage level is
lower than the preset low trigger level.
 RFALl: trigger on any edge of the input signal when the voltage level meets the
preset trigger level.
Return
Format
The query returns POS, NEG, or RFAL.
Example
:TRIGger:WINDows:SLOPe NEGative /*Set the windows type to NEGative*/
:TRIGger:WINDows:SLOPe? /*The query returns NEG*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
