Rigol DS1054Z Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-195
:TRIGger:DELay:TLOWer
Syntax
:TRIGger:DELay:TLOWer <NR3>
:TRIGger:DELay:TLOWer?
Description
Set or query the lower limit of the delay time in delay trigger. The default unit is s.
Parameter
Name
Type
Range
Default
<NR3>
Real
Related to the delay type
GREater: 8ns to 10s
GOUT or GLESs: 8ns to 9.99s
1μs
Explanation
This command is only available when the delay type (refer to :TRIGger:DELay:TYPe) is
GREater, GOUT, or GLESs.
Return
Format
The query returns the lower limit of the delay time in scientific notation.
Example
:TRIGger:DELay:TLOWer 0.002 /*Set the lower limit of the delay time to 2ms*/
:TRIGger:DELay:TLOWer? /*The query returns 2.000000e-03*/
Related
Command
:TRIGger:DELay:TUPPer

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
