Rigol DS1054Z Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-209
:TRIGger:IIC:CLEVel
Syntax
:TRIGger:IIC:CLEVel <level>
:TRIGger:IIC:CLEVel?
Description
Set or query the trigger level of SCL in I2C trigger. The unit is the same as the
current amplitude unit.
Parameter
Name
Type
Range
Default
<level>
Real
(-5 x VerticalScale - OFFSet) to
(5 x VerticalScale - OFFSet)
0
Explanation
 For VerticalScale, refer to :CHANnel<n>:SCALe. For OFFSet, refer
to :CHANnel<n>:OFFSet.
 This command is only available when the signal source of the clock line is an
analog channel.
Return Format
The query returns the trigger level of SCL in scientific notation.
Example
:TRIGger:IIC:CLEVel 0.16 /*Set the trigger level of SCL to 160mV*/
:TRIGger:IIC:CLEVel? /*The query returns 1.600000e-01*/
:TRIGger:IIC:DLEVel
Syntax
:TRIGger:IIC:DLEVel <level>
:TRIGger:IIC:DLEVel?
Description
Set or query the trigger level of SDA in I2C trigger. The unit is the same as the
current amplitude unit.
Parameter
Name
Type
Range
Default
<level>
Real
(-5 x VerticalScale - OFFSet) to
(5 x VerticalScale - OFFSet)
0
Explanation
 For VerticalScale, refer to :CHANnel<n>:SCALe. For OFFSet, refer
to :CHANnel<n>:OFFSet.
 This command is only available when the signal source of the data line is an
analog channel.
Return Format
The query returns the trigger level of SDA in scientific notation.
Example
:TRIGger:IIC:DLEVel 0.16 /*Set the trigger level of SDA to 160mV*/
:TRIGger:IIC:DLEVel? /*The query returns 1.600000e-01*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
