General| Channels | 4 |
|---|---|
| Bandwidth | 50 MHz |
| Sample Rate | 1 GSa/s |
| Memory Depth | 24 Mpts |
| Display | 7 inch TFT LCD (800x480) |
| Vertical Sensitivity | 1 mV/div to 10 V/div |
| Time Base Range | 5 ns/div to 50 s/div |
| Vertical Resolution | 8 bits |
| Trigger Types | Edge, Pulse, Video, Slope |
| Connectivity | USB Host, USB Device, LAN |
| Input Impedance | 1 MΩ |
| Power Supply | 100-240 VAC, 45-440 Hz |
