RIGOL Chapter 2 Command System
2-54 MSO1000Z/DS1000Z Programming Guide
:DECoder<n>:SPI:POLarity
Syntax
:DECoder<n>:SPI:POLarity <pol>
:DECoder<n>:SPI:POLarity?
Description
Set or query the polarity of the SDA data line in SPI decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<pol>
Discrete
{NEGative|POSitive}
POSitive
Explanation
 NEGative: . The low level is 1.
 POSitive: . The high level is 1.
Return
Format
The query returns NEG or POS.
Example
:DECoder1:SPI:POLarity NEG ative /*Set the polarity of the SDA data line in SPI
decoding to negative*/
:DECoder1:SPI:POLarity? /*The query returns NEG*/
:DECoder<n>:SPI:EDGE
Syntax
:DECoder<n>:SPI:EDGE <edge>
:DECoder<n>:SPI:EDGE?
Description
Set or query the clock type when the instrument samples the data line in SPI decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<edge>
Discrete
{RISE|FALL}
RISE
Return
Format
The query returns RISE or FALL.
Example
:DECoder1:SPI:EDGE FALL /*Set the instrument to sample data on the falling edge
of the clock in SPI decoding*/
:DECoder1:SPI:EDGE? /*The query returns FALL*/
:DECoder<n>:SPI:ENDian
Syntax
:DECoder<n>:SPI:ENDian <endian>
:DECoder<n>:SPI:ENDian?
Description
Set or query the endian of the SPI decoding data.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<endian>
Discrete
{LSB|MSB}
MSB
Return
Format
The query returns LSB or MSB.
Example
:DECoder1:SPI:ENDian MSB /*Set the data endian of the SPI decoding to MSB*/
:DECoder1:SPI:ENDian? /*The query returns MSB*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
