Rigol DS1054Z Programming Guide

RIGOL Chapter 2 Command System
2-60 MSO1000Z/DS1000Z Programming Guide
:DECoder<n>:PARallel:NRTime
Syntax
:DECoder<n>:PARallel:NRTime <time>
:DECoder<n>:PARallel:NRTime?
Description
Set or query the noise rejection time of parallel decoding. The default unit is s.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<time>
Real
0.00s to 100ms
0.00s
Explanation
Before sending this command, send the :DECoder<n>:PARallel:NREJect command to
turn on the noise rejection function.
Return
Format
The query returns the noise rejection time in scientific notation.
Example
:DECoder1:PARallel:NRTime 0.01 /*Set the noise rejection time to 10ms*/
:DECoder1:PARallel:NRTime? /*The query returns 1.000000e-02*/
:DECoder<n>:PARallel:CCOMpensation
Syntax
:DECoder<n>:PARallel:CCOMpensation <comp>
:DECoder<n>:PARallel:CCOMpensation?
Description
Set or query the clock compensation time of parallel decoding. The default unit is s.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<comp>
Real
-100ms to 100ms
0.00s
Explanation
 Setting the compensation time can make fine adjustment of the pahse deviation
between the clock line and data line.
 This command is invalid when the CLK channel source is set to OFF
(:DECoder<n>:PARallel:CLK).
Return
Format
The query returns the compensation time in scientific notation.
Example
:DECoder1:PARallel:CCOMpensation 0.01 /*Set the compensation time to 10ms*/
:DECoder1:PARallel:CCOMpensation? /*The query returns 1.000000e-02*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
