RIGOL Chapter 2 Command System
2-84 MSO1000Z/DS1000Z Programming Guide
:LA:DIGital<n>:POSition
Syntax
:LA:DIGital<n>:POSition <position>
:LA:DIGital<n>:POSition?
Description
Set or query the display position of the specified digital channel waveform on the screen.
Parameter
Name
Type
Range
Default
<n>
Integer
0 to 15
--
<position>
Integer
When the waveform display mode is SMALl: 0 to 15
When the waveform display mode is LARGe: 0 to 7
For the waveform display mode, refer to
the :LA:SIZE command
--
Explanation
 <position> (0 to 15 or 0 to 7) denotes the display position of the waveform on the
screen. When the waveform display mode is SMALl, 16 waveforms can be displayed
on the screen marked as 0 to 15 from top to bottom. When the waveform display
mode is LARGe, 8 waveforms can be displayed on the screen marked as 0 to 7 from
top to bottom.
 The setting command is only valid when the specified digital channel is turned on.
Return
Format
The query returns an integer from 0 to 15 or from 0 to 7.
Example
:LA:DIGital1:POSition 3 /*Set the display position of D1 to 3*/
:LA:DIGital1:POSition? /*The query returns 3*/
:LA:DIGital<n>:LABel
Syntax
:LA:DIGital<n>:LABel <label>
:LA:DIGital<n>:LABel?
Description
Set or query the label of the specified digital channel.
Parameter
Name
Type
Range
Default
<n>
Integer
0 to 15
--
<label>
ASCII
string
It can include English uppercase letters (A to Z)
and numbers (0 to 9).
It cannot exceed 4 characters.
--
Return
Format
The query returns the label of the specified digital channel in ASCII string. If the
specified channel has no label, the query returns "No Label".
Example
:LA:DIGital0:LABel ACK /*Set the label of D0 to ACK*/
:LA:DIGital0:LABel? /*The query returns ACK*/

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
