RIGOL Chapter 2 Command System

2-226 MSO1000Z/DS1000Z Programming Guide

:WAVeform:PREamble?

Syntax

:WAVeform:PREamble?

Description

Query and return all the waveform parameters.

Return

Format

The query returns 10 waveform parameters separated by ",":

<format>,<type>,<points>,<count>,<xincrement>,<xorigin>,<xreference>,<yincrem

ent>,<yorigin>,<yreference>

Wherein,

<format>: 0 (BYTE), 1 (WORD) or 2 (ASC).

<type>: 0 (NORMal), 1 (MAXimum) or 2 (RAW).

<points>: an integer between 1 and 24000000.

<count>: the number of averages in the average sample mode and 1 in other modes.

<xincrement>: the time difference between two neighboring points in the X direction.

<xorigin>: the start time of the waveform data in the X direction.

<xreference>: the reference time of the data point in the X direction.

<yincrement>: the waveform increment in the Y direction.

<yorigin>: the vertical offset relative to the "Vertical Reference Position" in the Y

direction.

<yreference>: the vertical reference position in the Y direction.

Example

:WAVeform:PREamble? /*The query returns

0,2,6000000,1,1.000000e-09,-3.000000e-03,0,4.132813e-0

1,0,122*/

Commands

:WAVeform:FORMat

:WAVeform:MODE

:ACQuire:AVERages

:WAVeform:XINCrement?

:WAVeform:XREFerence?

:WAVeform:YINCrement?

:WAVeform:YORigin?

:WAVeform:YREFerence?
