Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-151
[:TRACe[<n>]]:DATA:POINts
Syntax
[:TRACe[<n>]]:DATA:POINts volatile,<data>
[:TRACe[<n>]]:DATA:POINts? volatile
Description
Set or query the initial number of points of the arbitrary waveform of the specified signal
source channel.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
1
<data>
Integer
1 to 16384
2
Explanation
 This command initializes the voltage value of each point on the volatile waveform to
0μV automatically.
 After sending this command, you can use the [:TRACe[<n>]]:DATA:VALue
command to modify the voltage of the specified point.
Return
Format
The query returns an integer between 1 and 16384.
Example
:DATA:POINts volatile,512 /*Set the initial number of points of the source 1 arbitrary
waveform to 512*/
:DATA:POINts? volatile /*The query returns 512*/
[:TRACe[<n>]]:DATA:POINts:INTerpolate
Syntax
[:TRACe[<n>]]:DATA:POINts:INTerpolate <mode>
[:TRACe[<n>]]:DATA:POINts:INTerpolate?
Description
Set or query the interpolation mode of the editable points of the arbitrary waveform of
the specified signal source channel.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
1
<mode>
Discrete
{LINear|OFF}
OFF
Explanation
 LINear: turn on the linear interpolation. The waveform editor connects two editable
points using a straight line.
 OFF: turn off the linear interpolation. The waveform editor will keep a constant
voltage level between two editable points and create a ladder-like waveform.
Return
Format
The query returns LIN or OFF.
Example
:DATA:POINts:INTerpolate LIN /*Set the interpolation mode of the source 1 arbitrary
waveform to linear*/
:DATA:POINts:INTerpolate? /*The query returns LIN*/

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
