Rigol DS1104Z Plus Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-107
:MASK Commands
The :MASK commands are used to set and query the pass/fail test parameters.
Command List:
 :MASK:ENABle
 :MASK:SOURce
 :MASK:OPERate
 :MASK:MDISplay
 :MASK:SOOutput
 :MASK:OUTPut
 :MASK:X
 :MASK:Y
 :MASK:CREate
 :MASK:PASSed?
 :MASK:FAILed?
 :MASK:TOTal?
 :MASK:RESet
:MASK:ENABle
Syntax
:MASK:ENABle <bool>
:MASK:ENABle?
Description
Enable or disable the pass/fail test or query the status of the past/fail test.
Parameter
Name
Type
Range
Default
<bool>
Bool
{{1|ON}|{0|OFF}}
0|OFF
Explanation
The pass/fail test is invalid in the following conditions: the horizontal timebase is XY or
ROLL, in the slow sweep mode (namely when the horizontal timebase is YT, the
horizontal timebase is set to 200ms/div or slower) as well as during waveform record.
Return
Format
The query returns 1 or 0.
Example
:MASK:ENABle ON /*Enable the pass/fail test*/
:MASK:ENABle? /*The query returns 1*/

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
