Rigol DS1104Z Plus Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-103
:MATH:OPTion:SENSitivity
Syntax
:MATH:OPTion:SENSitivity <sens>
:MATH:OPTion:SENSitivity?
Description
Set or query the sensitivity of the logic operation. The default unit is div (namely the
current vertical scale).
Parameter
Name
Type
Range
Default
<sens>
Real
0 to 0.96, the step is 0.08
0
Explanation
This command is only applicable to logic operations (A&&B, A||B, A^B, and !A).
Return
Format
The query returns the current sensitivity in scientific notation.
Example
:MATH:OPTion:SENSitivity 0.24 /*Set the sensitivity of the logic operation to 0.24div*/
:MATH:OPTion:SENSitivity? /*The query returns 2.400000e-01*/
Related
Commands
:CHANnel<n>:SCALe
:MATH:OPERator
:MATH:OPTion:DIStance
Syntax
:MATH:OPTion:DIStance <dist>
:MATH:OPTion:DIStance?
Description
Set or query the smoothing window width of differential operation (diff).
Parameter
Name
Type
Range
Default
<dist>
Integer
3 to 201
3
Explanation
This command is only applicable to differential operation (diff).
Return
Format
The query returns an integer between 3 and 201.
Example
:MATH:OPTion:DIStance 25 /*Set the smoothing window width to 25*/
:MATH:OPTion:DIStance? /*The query returns 25*/
Related
Command
:MATH:OPERator

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
