Rigol DS1104Z Plus Programming Guide

RIGOL Chapter 2 Command System
2-44 MSO1000Z/DS1000Z Programming Guide
:DECoder<n>:UART
The :DECoder<n>:UART commands are used to set the RS232 decoding parameters.
Command List:
 :DECoder<n>:UART:TX
 :DECoder<n>:UART:RX
 :DECoder<n>:UART:POLarity
 :DECoder<n>:UART:ENDian
 :DECoder<n>:UART:BAUD
 :DECoder<n>:UART:WIDTh
 :DECoder<n>:UART:STOP
 :DECoder<n>:UART:PARity
:DECoder<n>:UART:TX
Syntax
:DECoder<n>:UART:TX <tx>
:DECoder<n>:UART:TX?
Description
Set or query the TX channel source of RS232 decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<tx>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|
D9|D10|D11|D12|D13|D14|D15|
CHANnel1|CHANnel2|CHANnel3|CHANnel4|OFF}
CHANnel1
Explanation
When OFF is selected, no TX channel source will be set. The TX channel source and RX
channel source (:DECoder<n>:UART:RX) cannot be both set to OFF.
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, CHAN4, or OFF.
Example
:DECoder1:UART:TX CHAN2 /*Set the TX channel source to CH2*/
:DECoder1:UART:TX? /*The query returns CHAN2*/

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
