Rigol DS1104Z Plus Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-45
:DECoder<n>:UART:RX
Syntax
:DECoder<n>:UART:RX <rx>
:DECoder<n>:UART:RX?
Description
Set or query the RX channel source of RS232 decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<rx>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|
D9|D10|D11|D12|D13|D14|D15|
CHANnel1|CHANnel2|CHANnel3|CHANnel4|OFF}
OFF
Explanation
When OFF is selected, no RX channel source will be set. The RX channel source and TX
channel source (:DECoder<n>:UART:TX) cannot be both set to OFF.
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, CHAN4, or OFF.
Example
:DECoder1:UART:RX CHAN4 /*Set the RX channel source to CH4*/
:DECoder1:UART:RX? /*The query returns CHAN4*/
:DECoder<n>:UART:POLarity
Syntax
:DECoder<n>:UART:POLarity <pol>
:DECoder<n>:UART:POLarity?
Description
Set or query the polarity of RS232 decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<pol>
Discrete
{NEGative|POSitive}
POSitive
Explanation
 NEGative: negative polarity ( ), namely high level is 0 and low level is 1. The
RS232 standard uses negative polarity.
 POSitive: positive polarity ( ), namely high level is 1 and low level is 0.
Return
Format
The query returns NEG or POS.
Example
:DECoder1:UART:POLarity NEGative /*Set the polarity of RS232 decoding to
negative*/
:DECoder1:UART:POLarity? /*The query returns NEG*/

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
