Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-223
:WAVeform:XREFerence?
Query the reference time of the specified channel source in the X direction.
The query returns 0 (namely the first point on the screen or in the internal memory).
:WAVeform:YINCrement?
Query the waveform increment of the specified channel source in the Y direction. The unit
is the same as the current amplitude unit.
The return value is related to the current data reading mode:
In NORMal mode, YINCrement = VerticalScale/25.
In RAW mode, YINCrement is related to the Verticalscale of the internal waveform and the
Verticalscale currently selected.
In MAX mode, YINCrement = VerticalScale/25 when the instrument is in running status;
YINCrement is related to the Verticalscale of the internal waveform and the Verticalscale
currently selected when the instrument is in stop status.
The query returns the YINCrement in scientific notation.
:WAVeform:YINCrement? /*The query returns 8.000000e-03*/
:WAVeform:YORigin?
Query the vertical offset relative to the vertical reference position of the specified channel
source in the Y direction.
The return value is related to the current data reading mode:
In NORMal mode, YORigin = VerticalOffset/YINCrement.
In RAW mode, YORigin is related to the Verticalscale of the internal waveform and the
Verticalscale currently selected.
In MAX mode, YORigin = VerticalOffset/YINCrement when the instrument is in running
status; YORigin is related to the Verticalscale of the internal waveform and the
Verticalscale currently selected when the instrument is in stop status.
The query returns an integer.
:WAVeform:YORigin? /*The query returns 25*/
:WAVeform:SOURce
:WAVeform:YREFerence?
