Rigol DS1104Z Plus Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-69
:ETABle<n>:ROW
Syntax
:ETABle<n>:ROW <row>
:ETABle<n>:ROW?
Description
Set or query the current row of the event table.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<row>
Integer
1 to the maximum number of rows of the
current event table
1
Return
Format
The query returns the current row in integer. If the current even table is empty, the
query returns 0.
Example
:ETABle1:ROW 2 /*Set the current row to 2*/
:ETABle1:ROW? /*The query returns 2*/
:ETABle<n>:SORT
Syntax
:ETABle<n>:SORT <sort>
:ETABle<n>:SORT?
Description
Set or query the display type of the decoding results in the event table.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<sort>
Discrete
{ASCend|DESCend}
ASCend
Explanation
 ASCend: the events are displayed in the order in which they occurred.
 DESCend: the events are displayed in the order reverse to the order in which they
occurred.
Return
Format
The query returns ASC or DESC.
Example
:ETABle1:SORT DESCend /*Set the display type of the event table to descend*/
:ETABle1:SORT? /*The query returns DESC*/

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
