RIGOL Chapter 2 Command System
2-78 MSO1000Z/DS1000Z Programming Guide
:FUNCtion:WREPlay:FCURrent
Syntax
:FUNCtion:WREPlay:FCURrent <cur>
:FUNCtion:WREPlay:FCURrent?
Description
Set or query the current frame in waveform playback.
Parameter
Name
Type
Range
Default
<cur>
Integer
1 to the maximum number of
frames recorded
The maximum number
of frames recorded
Explanation
 Use the :FUNCtion:WRECord:FEND command to set the maximum number of
frames recorded.
 You can only set the current frame of waveform playback when a waveform is
currently recorded.
 You cannot set the current frame of waveform playback during the waveform
recording or playback process.
Return
Format
The query returns an integer.
Example
:FUNCtion:WREPlay:FCURrent 300 /*Set the current frame in waveform playback to
300*/
:FUNCtion:WREPlay:FCURrent? /*The query returns 300*/

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
