Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-71
:FUNCtion Commands
The :FUNCtion commands are used to set the waveform recording and playback parameters.
Command List:
 :FUNCtion:WRECord:FEND
 :FUNCtion:WRECord:FMAX?
 :FUNCtion:WRECord:FINTerval
 :FUNCtion:WRECord:PROMpt
 :FUNCtion:WRECord:OPERate
 :FUNCtion:WRECord:ENABle
 :FUNCtion:WREPlay:FSTart
 :FUNCtion:WREPlay:FEND
 :FUNCtion:WREPlay:FMAX?
 :FUNCtion:WREPlay:FINTerval
 :FUNCtion:WREPlay:MODE
 :FUNCtion:WREPlay:DIRection
 :FUNCtion:WREPlay:OPERate
 :FUNCtion:WREPlay:FCURrent
:FUNCtion:WRECord:FEND
Syntax
:FUNCtion:WRECord:FEND <frame>
:FUNCtion:WRECord:FEND?
Description
Set or query the end frame of waveform recording.
Parameter
Name
Type
Range
Default
<frame>
Integer
1 to the maximum number of frames can be
recorded currently
5000
Explanation
Use the :FUNCtion:WRECord:FMAX? command to query the maximum number of frames
can be recorded currently.
Return
Format
The query returns the current end frame in integer.
Example
:FUNCtion:WRECord:FEND 4096 /*Set the end frame to 4096*/
:FUNCtion:WRECord:FEND? /*The query returns 4096*/
